I am trying to model claim counts over for a given region. The data is very sparse. I am using the BESAG model from R INLA package. I am having a tough time to model the data. I am able to reproduce my issue (to some extent) by some synthetic data generated as follows:

  1. Create a grid of 50x50 cells.
  2. Use a variogram to simulate some spatial effect (copied the R snippet from here)
  3. Create a artificial population residing in one of the 2500 cells.
  4. For each individual create a Poisson count response with mean = exponential of simulated spatial effect. The mean is artificially kept low so that I can have sparse data.
  5. To this synthetic data, fit Besag model (CAR model) from INLA and GAM.
  6. Plot the estimates on the map.

Here is my issue, as captured in the image below, the BESAG model is really showing estimates to be near 1. GAM works somewhat ok but it seems to over smooth the results. I can confirm that BESAG and GAM works well when I have plenty of data. My question is that are there techniques that I can use to handle the sparsity in my data? I have also provided the R script below (its a messy and tedious but should yield the same charts as shown in the post here).

enter image description here

enter image description here

I also want to say that I had tried another approach where in I redefined the 50x50 grid into a voronoi diagram with cell centroids having > 0 counts as the midpoints. I then reassigned the population to that new shapefile and fitted both GAM and BESAG models to this new spatial dataset. That did not work either. Here is how the revised shapefile looks like: enter image description here

(apologies in advance for messy and tedious script):

Load in the packages and some functions

library(raster)
library(rgdal)
library(rgeos)
library(sp)
library(spdep)
library(nimble)
library(scales)
library(ggmap)
library(viridisLite)
library(viridis)
library(MASS)
library(condMVNorm)
library(gstat)
library("gplots")
library(data.table)
library(lubridate)
library(splitstackshape)
library(INLA)
library(mgcv)
library(gridExtra)
memory.limit(3200000000000)

    # Grid size n_grid x n_grid
n_grid = 50
# Number of regions to simulate
n_sim <- 4
# Synthetic data size
size_pop = 400000
#used for variogram simulation
psill <- 0.15

sample_spatial_effect <- function(n_grid,psill, seed){
  xy <- expand.grid(1:n_grid, 1:n_grid)
  names(xy) <- c("x","y")

  # define the gstat object (spatial model)
  g.dummy <- gstat(formula=z~1, locations=~x+y, dummy=T,
                   beta=1, model=vgm(psill=0.15,model="Exp",range=25), nmax=20)


  set.seed(seed)
  # make four simulations based on the stat object
  yy <- predict(g.dummy, newdata=xy, nsim=4)

  gridded(yy) = ~x+y
  return(yy)
}

plot_spatial_effect <- function(p,attribute, title){
  # p@data$id = row.names(p_1@data)
  newp <- fortify(p, region = "id")
  newdf_1 <- merge(newp, p@data, by = "id")

  Myplot <- ggplot() +

    geom_polygon(data = newdf_1, aes_string(fill = attribute,
                                            x = "long",
                                            y = "lat",
                                            group = "group")) +
    theme_minimal() + coord_map() + ggtitle(title) + theme(plot.title = element_text(hjust =0.5))

  NicerPlot <- Myplot + scale_fill_viridis(option = "magma", direction = -1)
  return(NicerPlot)
}

Simulate four maps and I decided to choose simulation 2 from the results below Simulated effects, sim 2 will be used to synthesize data

The code for simulating effects is as below

# Simulate some spatial effect over a grid of 50x50
yy <- sample_spatial_effect(n_grid,psill, 800000)
yy_exp = yy
yy_exp@data = exp(yy_exp@data)

# show all four simulations but choose simulation 2 for generating data
spplot(yy_exp)

# Convert to spdf, create id (used later for joins)
p_1 <- as(yy, "SpatialPolygonsDataFrame")
p_1@data$id = row.names(p_1@data)
# Append simulated spatial effects
newp <- fortify(p_1, region = "id")
newdf_1 <- merge(newp, p_1@data, by = "id")

Now create synthetic data

####################################################################
# Select simulation 2
sel_eff = "sim2"
spatial_effects <- as.data.table(unique(newdf_1[, c("id",sel_eff)]))
setnames(spatial_effects, old = sel_eff, new = "spatial_eff")

# Generate a sample population
sample_pop <- {}
sample_pop <- data.table("id" = sample(n_grid*n_grid, size = size_pop, replace = TRUE))
sample_pop[, c("id"):= list(paste0("g",id)),]

# Append spatial effect to each individual in the population
setkey(spatial_effects,id)
setkey(sample_pop, id)
sample_pop <- spatial_effects[sample_pop]
# Create a unique key for each record
sample_pop[, c("globalid") := list(seq_len(.N))]
# Define mean of poisson count variable as below
sample_pop[, c("mean_pois") := list(exp(spatial_eff))]

# Define and append centroids of the regions to the sampled data, will be used in GAM regression
centroids <- (sp::coordinates(p_1))
id_centroids <- row.names(centroids)

centroids <- as.data.table(centroids)
centroids$id <- id_centroids

setkey(sample_pop, id)
setkey(centroids, id)

sample_pop <- centroids[, list(id, x_coord = V1, y_coord = V2)][sample_pop]
sample_pop$weights <- 1

# Simulate some data so that overall number of counts/number of records are equal to
# the defined frequency specified by .0005
avg_freq <- mean(sample_pop$mean_pois)
req_freq = 0.002
intercept <- log(req_freq/avg_freq)
sample_pop[, c("mean_pois") := list(exp(intercept + spatial_eff))]
set.seed(3)
sample_pop$sim_count <- rpois(nrow(sample_pop), sample_pop$mean_pois)

# Compute simulated freq
sim_freq = sum(sample_pop$sim_count)/sum(sample_pop$weights)

Fit a GAM on the dataset with gaussian process smoother

# Fit a gam with x and y coordinates, use GP smoother
gam_model_latlon <- mgcv::bam(sim_count ~ s(x_coord, y_coord, bs = "gp", m = 3, k = 100)
                              ,data = sample_pop, family=poisson(link=log),
                              weights = weights,discrete = TRUE)

Make GAM predictions to get the spatial effect

# Compute predictions from GAM (used for pl)
# Idea is to list out the unique x y coordinates for the cells in the grid
dummy_data <- expandRows(sample_pop[1,], count = nrow(centroids), count.is.col = FALSE)
dummy_data[, c("id", "x_coord", "y_coord") := list(centroids$id, centroids$V1, centroids$V2),]
dummy_data$gam_spatial_est <- exp(predict.gam(gam_model_latlon, newdata=dummy_data))

summ_code <- sample_pop[, list(obs_counts = sum(sim_count), fitted_counts = .N*sim_freq,
                               weights = sum(weights)), keyby = list(id)][, c("res") := list(obs_counts/fitted_counts),]
# Append summarized data to the shape file
shape_fulldata <- merge(x = p_1, y = summ_code, by = "id",all.x = TRUE)

Now create the neighbourhood matrix and fit BESAG model using INLA

# Create a neighbourhood list
nb <- poly2nb(shape_fulldata)
listw <- nb2listw(nb, style="W", zero.policy=TRUE)

# Compute Moran's I
moran_org <- moran.test(shape_fulldata$res,listw, alternative="greater")
# Provide neighbourhood list in INLA format and run INLA
nb2INLA("map_test.adj", nb)
g <- inla.read.graph(filename = "map_test.adj")
shape_fulldata$idareau <- 1:nrow(shape_fulldata@data)
formula_besag <- obs_counts ~ f(idareau, model = "besag", graph = g, scale.model = TRUE)
res_besag <- inla(formula_besag,family = "poisson", data = shape_fulldata@data,
                  E = fitted_counts, control.predictor = list(compute = TRUE), verbose = FALSE)
# Select the INLA fitted effect
shape_fulldata@data$fitted_u <- res_besag$summary.fitted.values$mean

Combine the predictions from INLA and GAM. Plot them against the actual simulated effect

# Append fitted effect from GAM done earlier
dummy_data_sp <- dummy_data[, list(id, gam_spatial_est)]
shape_fulldata <- merge(x = shape_fulldata, y = as.data.frame(dummy_data_sp), by = "id", all.x = TRUE)

# Compute the weighted means and use it scale actual and individual model's estimate.
# It makes plotting a bit easier
shape_fulldata$sim_exp = exp(shape_fulldata@data[,sel_eff])
actual_mean <- weighted.mean(shape_fulldata$sim_exp, shape_fulldata$weights)
inla_mean <- weighted.mean(shape_fulldata$fitted_u, shape_fulldata$weights)
gam_mean <- weighted.mean(shape_fulldata$gam_spatial_est, shape_fulldata$weights)

#Scale actual and predicted values
shape_fulldata$fitted_u <- shape_fulldata$fitted_u/inla_mean
shape_fulldata$sim_exp <- shape_fulldata$sim_exp/actual_mean
shape_fulldata$gam_spatial_est <- shape_fulldata$gam_spatial_est/gam_mean

# Plot the cells with count > 0 along with fitted and actual effects
shape_fulldata@data$count_ind <- ifelse(shape_fulldata@data$obs_counts > 0, 1,0)
grid.arrange(plot_spatial_effect(shape_fulldata, "count_ind", "Cells with >0 counts"),
             plot_spatial_effect(shape_fulldata, "fitted_u", "INLA Estimate"),
             plot_spatial_effect(shape_fulldata, "gam_spatial_est", "GAM Estimate"),
             plot_spatial_effect(shape_fulldata, "sim_exp", "Actual"),
             ncol = 2, nrow = 2
)

# Plot the empirical distribution of fitted vs actual effects
estimates_dt <- as.data.table(shape_fulldata@data[, c("id", "fitted_u", "gam_spatial_est", "sim_exp", "weights")])
names(estimates_dt) <- c("id", "INLA", "GAM", "Actual", "weights")
estimates_dt <- melt.data.table(data = estimates_dt, id.vars = c("id","weights"),
                                measure.vars = c("INLA", "GAM", "Actual"),
                                variable.name = "model_fits", value.name = "estimates")
plot(ggplot(estimates_dt, aes(x = estimates, colour = model_fits, weight = weights)) + geom_freqpoly( bins = 50))

I have provided the charts above (the above two plots help in creating them).
