How to estimate mean and variance for rate of change when I only have state data at different ages

Question

I'll give you the intuition behind my problem first. I have data on whether children ($n \approx 200$) can read and their age in integers from 0 to 14.

For each age, it is straightforward to calculated the expected value $$E(read|age=age_t) = \frac{k}{n}.$$

For instance, if I observe 5 children at age 6 who can read and 5 who cannot, the expected value of $read$ given $age = 6$ is 0.5. If I then observe 7 children and who can read and 3 who cannot at age 7, I might think intuitively that 20 percent of children have learned to read at age 6 (assuming the sample is random and there is no attrition).

What I am really interested in is the rate of change in the state variable $read$. I want to know the mean age at which children learn to read, and the variance of that new variable. As a first pass, I have tried to tackle this discretely by calculating $\Delta read_t = E(read|age = age_{t+1}) - E(read|age = age_t)$ for each age. Then I take $\sum_{t=0}^{13}age_t \times \Delta read_t$ to be the mean value at which children learn to read.

---

I'm aware that this is not an adequate approach to this problem, but I'm trying to think it through. My reasoning is that I think of the number of children who can read at each age to be like a cdf for the variable "when learned to read." The rate of change is then analogous to the pdf, and I can find the expected value of "when learned to read" in the normal way.

However, each $E(read|age=age_t)$ is itself a random variable, so the cdf is not strictly increasing because the observed outcome of $read$ for an older age group might be lower than for a younger one. I would also ideally like to be able to construct valid confidence intervals and have a better grasp on the problem in general. I should also add that this is historical data, so the final outcome for reading is not 100% literacy, but more like 70%. I suspect that I'll have to normalize the variable in some way.

Any help or guidance is very welcome. I suspect the problem will involve maximum likelihood estimation using some combination of a normal and binomial distribution. I've explored this method somewhat, but I feel like I'm at a bit of a roadblock and would appreciate some guidance before proceeding. Is what I am attempting even possible?

Answer 1

Suppose the age when children learn to read is distributed normally, with mean $m$ and standard deviation $s$. Then the fraction of children who can read at age $a$ is $\Phi((a-m)/s)$. (Here, $\Phi$ is the cumulative distribution function for the standard normal, and we'll also want its inverse $\Phi^{-1}$ which calculates quantiles or $z$-scores.)

So for this model, we are looking for $m$ and $s$ which best fit the equation $$\frac{a_t - m}{s} = \Phi^{-1}\left(\frac{k_t}{n_t}\right)$$

We can approximate this using a simple linear regression to determine $$\Phi^{-1}\left(\frac{k_t}{n_t}\right) = \beta_1 a_t + \beta_0$$ and then taking $$m=\frac{-\beta_0}{\beta_1}, \ \ s=\frac{1}{\beta_1}.$$

This is a first approximation; the data points can also be weighted, as suggested by whuber here, which gives a more admissible answer.

Answer 2

Build a common regression model with age and year as predictors. Since the response is binary (reading or not ...), logistic regression is a natural starting point. That is, $$ \DeclareMathOperator{\P}{\mathbb{P}} \P(Y_i=1 \mid a, t) =p_{a,t} $$ where $a$ is age and $t$ is timepoint. Since the expectation of a binary (0/1) variable is its expectation, $p_{a,t}$ corresponds to your $E(read|age=age_t)$ (I find that notation ambiguous so avoid it.) With a binomial distribution for $Y_i$ and a logistic link function (you could try other links) we get $$ \operatorname(logit)(p_{a,t} = \mu + \alpha a + \beta t ) $$ for a linear model, but you could try other models. I will simulate from a linear model, but show a fit with a spline for $t$, using glm in R. An alternative could be mgcv which is more automatic.

n <- 200
set.seed(7*11*13) # My public seed

# First a linear model:

year <- rep( seq.int(from=-25, to=25, by=3) , each=ceiling(n/17) )
age  <- sample(5:14, size=length(year), replace=TRUE)
p <-     -0.1482 +age*(.5/9)+year*(0.3/98)
   # This gives too many small probabilities ... so change for a more
   # representative simulation ...
Y    <- rbinom(length(year), size=1, p=p )

mydata <- data.frame(year,  age, p)

Then we fit a model, and show a plot of the fitted spline:

library(splines)
mod0 <-  glm( Y  ~ age + ns(year, df=4), data=mydata, family=binomial) # alternatively mgcv

summary(mod0)
anova(mod0, test="Chis")

Yhat <- predict(mod0, type="resp")
### Output from summary and anova:
summary(mod0)
anova(mod0, test="Chis")

Call:
glm(formula = Y ~ age + ns(year, df = 4), family = binomial,
    data = mydata)

Deviance Residuals:
    Min       1Q   Median       3Q      Max
-1.7770  -0.8661  -0.5005   1.0026   2.1880

Coefficients:
                  Estimate Std. Error z value Pr(>|z|)
(Intercept)       -4.60462    0.89591  -5.140 2.75e-07 ***
age                0.38446    0.06806   5.649 1.61e-08 ***
ns(year, df = 4)1  0.28385    0.78697   0.361   0.7183
ns(year, df = 4)2  1.46611    0.75326   1.946   0.0516 .
ns(year, df = 4)3  0.16797    1.45083   0.116   0.9078
ns(year, df = 4)4 -0.06443    0.65292  -0.099   0.9214
---
Signif. codes:  0 ‘***’ 0.001 ‘**’ 0.01 ‘*’ 0.05 ‘.’ 0.1 ‘ ’ 1

(Dispersion parameter for binomial family taken to be 1)

    Null deviance: 271.40  on 203  degrees of freedom
Residual deviance: 226.88  on 198  degrees of freedom
AIC: 238.88

Number of Fisher Scoring iterations: 4

>
Analysis of Deviance Table

Model: binomial, link: logit

Response: Y

Terms added sequentially (first to last)


                 Df Deviance Resid. Df Resid. Dev  Pr(>Chi)
NULL                               203     271.40
age               1   38.626       202     232.78 5.133e-10 ***
ns(year, df = 4)  4    5.893       198     226.88    0.2073
---
Signif. codes:  0 ‘***’ 0.001 ‘**’ 0.01 ‘*’ 0.05 ‘.’ 0.1 ‘ ’ 1

### Let us get terms predictions to plot the estimated spline

Yhat.terms <- predict(mod0, type="terms")

The code for the plot is:

library(ggplot2)

ggp <- ggplot( within(mydata, {spline <- Yhat.terms[, "ns(year, df = 4)"]
                               Yhat <- Yhat} ),
              aes(y=spline, x=year) )

ggp + geom_point( color="red") + ggtitle("Fitted spline of year")
